Linear RF Power Amplifier

Elite RF’s AB.02018G4348AC amplifier is two wideband power amplifiers in one cabinet designed for CW signals fabricated on GaN on SiC process and can operate up to 18 GHz. This amplifier offers high power low density, decade thermal resistance, bandwidth performance, and wideband performance. It can be widely used for military and commercial applications.

Specifications

• Frequency Range: 20 MHz to 18 GHz

• Output Power CW: 20 Psat Watts

• Gain (dbm): 48

• Mode: CW (Continuous Wave)

• AC Operating Voltage: 100-240 VAC, 120 VAC (typ)

• Size: 19.0 x 15.0 x 3.5

AB Series

Elite RF’s 6.0GHz to 18.0GHz RF Power Amplifiers incorporate advanced, state-of-the-art RF GaN transistors, reflecting our commitment to advanced engineering. These class AB linear amplifiers are designed for power gain up to 48dB, operate in CW or pulse mode, and feature built-in protection and enable/disable functions. Different frequency bands and saturated power requirements can be configured into various form factors like modules (MB series), racks (AB series), racks with display (DB series) as per customers’ requirements.

Series Features

• Wide Freq. Range

• High Output Power

• High Gain

• High Reverse Isolation

• Built-in Protection

• Indicator Options

• DC Power

• Temp Fault

• Protections

• Thermal Overload

• Over Voltage

• Reverse Polarity

What's in the Box

• AB.02018G4348AC Amplifier

• AC Power Cord

• Certificate of Conformance

• 2 Year Warranty

• Calibration not required
