MSOX6004JIT High Speed/Jitter Application Bundle

The High-Speed Signal Integrity / Jitter Best Bundle is built around the MSOX6004A 4-channel, 2.5-GHz bandwidth InfiniiVision 6000 X-Series mixed signal oscilloscope (MSO) that samples at rates up to 20 GSa/s and comes with a built-in 2-channel function / arbitrary waveform generator(AWG), as well as the ultimate bundle software package.

The ultimate bundle software package includes all software options available in the InfiniiVision 6000 X-Series oscilloscopes, including high-speed jitter analysis. Jitter analysis on the InfiniiVision 6000 X-Series oscilloscope measures various types of jitter with multiple views and quantization of jitter to provide you with valuable insight into the source of unwanted timing error .

Also included is a broad range of automotive and embedded serial bus trigger and decoding capabilities including USB 2.0 low-, full-, and hi-speed, as well as frequency response analysis (Bode plots) and automated pass / fail limit testing based on either measurement limits or waveform mask limits.

MSOX6004JIT High-Speed / Jitter Best Bundle Includes:

• MSOX6004A 4+16 channel, 1-GHz mixed signal oscilloscope
• DSOX6004A-02G 2.5-GHz bandwidth option
• D6000BDLB Ultimate bundle software option
• DSOX6WAVEGEN2 2-channel function / arbitrary waveform generator(AWG)
• N2751A 3.5-GHz differential active probe

Testing for timing margins and unwanted jitter in high-speed digital systems requires oscilloscopes with fast sample rates, active probes, and automated jitter analysis with software clock recovery. Keysight’s InfiniiVision oscilloscope better and best high-speed jitter application bundles provide you with all these critical measurement tools to perform jitter analysis on your hig -speed serial buses.

InfiniiVision X Series Oscilloscope Application Bundles

Deciding which probes, which hardware upgrades, and which software options to purchase along with your InfiniiVision X-Series oscilloscope for a specific measurement application can be a daunting task. Keysight has made it easy for you by pre-configuring multiple products under single bundled model numbers. Keysight now offers six different bundles of products optimized for automotive test and debug, power supply characterization and testing, and high-speed signal integrity / jitter testing. Choose the one that best fits your measurement application and budget and save 25% off the list price relative to purchasing the same items individually.

Six Bundles to Choose From

• Automotive Better Application Bundle (DSOX3054AUT)
• Automotive Best Application Bundle (MSOX4254AUT)
• Power Better Application Bundle (DSOX3054PWR)
• Power Best Application Bundle (MSOX4254PWR)
• High-speed/Jitter Better Application Bundle (DSOX6004JIT)
• High-speed/Jitter Best Application Bundle (MSOX6004JIT)
