RIGOL Mixed-Signal Oscilloscopes and Real-Time Spectrum Analyzers
TestEquity is proud to be an authorized RIGOL distributor. With a reputation for quality, value and innovation, RIGOL is a trusted test and measurement solution provider across industries. Its MSO5000 and 1000Z mixed-signal oscilloscopes series, and RSA3000 and RSA5000 real-time spectrum analyzers offer best-in-class performance and features that meet the most critical design challenges.
MSO5000 Series | Mixed-Signal Oscilloscopes
The MSO5000 combines premium sampling and memory depth with a modern, flexible user interface driven by Rigol’s new UltraVision II architecture and state-of-the-art Phoenix Chipset. Analyze critical signals with zone triggering, 7 instruments in 1, enhanced FFTs, color grading, and histograms all supported by the high sample rate, deep memory, and full memory measurements.
- 70 to 350 MHz models, each with 2 or 4 analog channels
- Up to 8 GSa/s real-time sample rate
- Up to 200 Mpts memory depth (option)
- High waveform capture rate (over 500,000 wfm/s)
1000Z Series | Mixed Signal Oscilloscopes
The 1000Z Series is Rigol’s digital oscilloscope platform for basic visualization, offering unprecedented value through technology innovations, industry-leading specifications, powerful trigger functions, and broad analysis capabilities.
- 4 channel oscilloscopes come in 50, 70, or 100 MHz versions
- 7-inch display
- UltraVision technology
- Real-time sample rate up to 1 GSa/s
DS1000Z-E Series, in 100 and 200 MHz, 2 Channel models, are also part of the product family. “S” models include a 2-channel integrated waveform generator. PLUS models are upgradable to mixed-signal oscilloscopes with the purchase of the RPL1116 digital lead kit.
RSA3000 Series | Real-Time Spectrum Analyzers
Engineers integrating WiFi, Bluetooth and other modern RF technologies face complex challenges like frequency hopping signals, channel conflict, and spectrum interference. RSA3000 and RSA3000E Series combine high-performance swept analysis and real-time performance (9.3µs 100% POI) with specialized optional measurement modes for demanding analysis including EMI mode for EMI Pre-Compliance testing, ASK/FSK mode for demodulation analysis (RSA3000E), and AMK for Advanced Measurements including channel parameters.
- Ultra-Real technology
- Frequency: up to 3 GHz
- Displayed average noise level (DANL): <-161 dBm (typical)
- Phase noise: <-102 dBc/Hz (typical)
RSA3000N models also come standard with Vector Network Analysis. VNA Mode includes S11, S21, and Distance to Fault measurements.
RSA5000 | Real-Time Spectrum Analyzers
The RSA5000 Series combines high-performance swept analysis and real-time performance (7.45µs 100% POI) with a 10.1-inch capacitive multi-touch screen. Specialized optional measurement modes for demanding analysis include EMI mode for EMI pre-compliance testing, VSA mode for complex demodulation analysis, and AMK for advanced measurements including channel parameters.
- Ultra-Real technology
- Frequency: up to 6.5 GHz
- Displayed average noise level (DANL): <-165 dBm (typical)
- Phase noise: <-108 dBc/Hz (typical)
RSA5000N models include Vector Network Analysis. VNA Mode includes S11, S21, and Distance to Fault measurements. The RSA5000 provides complete characterization of RF components, modules, and systems with uncompromised performance and unprecedented value.
NEW - DS8000-R Series Oscilloscope
The DS8000-R Series packs RIGOL’s UltraVision II technology into a rack-mount format. Ideal for data collection and archiving, DS8000-R scopes stand out in applications with large channel systems and high throughput requirements. What’s more, it meets the standards of industrial automation test systems.
- 4-channel oscilloscope
- 10 GSa/s sample rate
- 500 Mpts memory depth
- 600 kwfm/s waveform capture rate
